Warm Audio WA-412
Mic. Preamp Warm Audio WA-412Mic. Preamp Warm Audio WA-412 (2)Mic. Preamp Warm Audio WA-412 (3)

Warm Audio WA-412

  • Number of channels: 4
  • Phantom Power: 48 V
  • Features: Altran USA Custom wound Premium input/output transformers
  • Displays: LED
  • Inputs and Outputs: 4x XLR inputs
  • Dimensions W/H/D: 19"/1U
more
less

Warm Audio WA-412 · Mic. Preamp

The Warm Audio WA-412 offers 4 channels of the classic "American console sound" in a slim 1U cabinet. The microphone and instrument preamp delivers large, expressive depths and open silky heights. Equipped with 100% discrete 6pin operational amplifiers and custom Altran USA transmitters in the inputs and outputs, the WA-412 offers an incredible price-performance ratio and delivers everything that the ears desire.

More features.

The WA-412 offers all the features that a user expects from the WA-412 model... and more. The WA-412 has a TONE switch in each channel for switching the impedance from 150 Ohm to 600 Ohm as well as the classic functions and controls such as a 48V phantom power switch, phase reverse switch, mic / line switch and a -20 dB pad An output trim that allows you to work creatively with gain and saturation.

Better components.

Each channel is equipped with a 100% discrete 6-pin opamp, which is placed on a base and can be replaced if necessary. Discrete opamp circuits are known to provide a high headroom and to generate little distortion. And that's exactly what they do in the WA-412. In addition, specially wound transformer transformers - Made In USA - are used in the inputs and outputs, which are responsible for the clear and open character of the WA-412.

The careful choice of high-quality components has made the WA-412 a real workhorse, delivering top-notch quality and giving the signal a touch of vintage console magic.

  • 4-channel microphone and instrument amplifier
  • 100% discrete, transformer balanced circuit
  • Altran USA Custom Wrapped Premium Input and Output Transformer
  • X520 operational amplifier in each channel (can be exchanged, if necessary, as they are socketed)
  • 65 dB gain
  • Transmitter balanced XLR & active instrument inputs
  • Transmitter-balanced XLR and jack outputs
  • TONE switch changes the impedance of the microphone and instrument preamp from 600 to 150 Ohm
  • - 20 dB pad (affects microphone and instrument preamps)
  • + 48V phantom power
  • LED Metering
  • Output trim control for precise volume control and saturation effects
  • Internal power supply
  • 19"/ 1HE
